5083 Aluminum Plate
Thickness:0.016-0.2mm
Port of Destination:Any port you like.
Port of Destination:Any port you like.
Consultation
Service hotline
0769-85391069
0769-85391069
Properties
Alloy 5083 aluminum plates retain good formability due to excellent ductility. It has higher strength (compared to 5052) and exceptional thermal conductivity. For its excellent resistance to corrosion and extremely low temperatures without brittleness or change of properties, 5083 is highly suitable for marine applications.
| Alloy | 5083 | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Temper | O | H32 | H34 | H112 | ||||||
| Thickness (mm) | >3.0-6.0 | >6.0-12.5 | >12.5-50 | >50.0-80.0 | >3.0-6.0 | >3.0-6.0 | >6.0-12.5 | >12.5-40.0 | >40.0-80.0 | |
| Width (mm) | 500-3100 | |||||||||
| Length (mm) | ¡Ü16000 | |||||||||
|
Tensile Strength £¨Mpa£© |
National Standard | 275-350 | 270-345 | 305-380 | 340-400 | ¡Ý275 | ¡Ý270 | |||
| Internal Control | 275-350 | 270-345 | 305-380 | 340-400 | ¡Ý275 | ¡Ý270 | ||||
| Elonggation (%) | ¡Ý15 | ¡Ý16 | ¡Ý15 | ¡Ý14 | ¡Ý8 | ¡Ý7 | ¡Ý12 | ¡Ý10 | ¡Ý10 | |
Applications
Due to its good formability, high strength, excellent resistance to correction,5083 aluminum plate is vastly used for ship construction, pressure vessels, storage tanks, armor plate, etc.
